ALMAC Washer Extractors are characterized by their compact, robust design and reliable technology. The computer panel has super UI and excellent programs to ease the washing process. User can control work liquid-level, wash temperature, wash time and efficiently satisfy with wash request in different situations. The high extraction speeds considerably reduce drying time, resulting in energy and time savings in the drying process.
Stainless Steel Drum:
Both the Washer Extractor body and the inner drum is made of high quality of stainless steel with the advantages of smooth surface, high strength and durability and resistant to corrosion.
Efficient Drum Action
The frequency-controlled motor helps ensure quality by providing flexibility in the drum action, such as an extra gentle wash for delicate garments. Efficient extraction sequence that minimizes water and energy consumption is an additional benefit.
Fast & Effective Water Extraction
ALMAC washer extractors provide high G-Force extraction that ensures high water removal capacity. Less water in the garments when the cycle is complete means less time and energy needed in the drying and finishing process.The higher the G- Force during the extraction, the lower the water retention of the fabrics being processed; hence we have designed for High G- Force resulting to reduce the drying cycle and finishing time thus saving power consumption by 35 to 40%.
Automatic Detergent Dispenser
Our machines are prepared for manual dosage of powder detergents, connection to a system for liquid injection, or a combination of both. Signals for additional supply of detergents are also available
Perfectly Balanced Drum Assembly
The drum assembly on our high-spin models rests on heavy steel springs and shock absorbers. This ensures a perfect balance for low noise and smooth operation. Robust industrial ball bearings and gaskets ensure long life.
Efficient Drive System
Equipped with inverter, the machine has the advantages of energy savings as it reduces the peak energy demand and facilitate stable running. Four kinds of speeds in washing can be obtained such as washing, distributing, middle –speed and high-speed extracting can be obtained.
| MODEL | XGQ-100 | XGQ-80 | XGQ-50 | XGQ-25 | XGQ-15 |
|---|---|---|---|---|---|
| Capacity | 100 | 80 | 50 | 25 | 15 |
| Drum (DxL)mm | 1240 x 840 | 1150 x 800 | 990 x 660 | 810 x 520 | 650 x 460 |
| Cylinder (DxL) | 1326 x 953 | 1216 x 918 | 1060 x 754 | 870 x 615 | 710 x 533 |
| Washing/Distributing Speed (RPM) | 30/60 | 30/60 | 40/60 | 43/75 | 45/82 |
| Middle/High Extracting Speed (RPM) | 325/650 | 360/700 | 375/750 | 430/810 | 440/920 |
| Work Cycle Time (mins) | 45 | 45 | 45 | 45 | 45 |
| Motor Power (Kw) | 7.5 | 6.5 | 4 | 3 | 1.5 |
| Electric Heater (Kw) Elec.Heating | - | - | 45 | 22.5 | 12 |
| Steam Pipe (DN) mm | 25 | 25 | 20 | 20 | 15 |
| Cool/Hot Water Pipe DN (mm) | 40 | 25 | 25 | 25 | 20 |
| Water Consumption /Cycle (Ltr) | 1800 | 1200 | 750 | 400 | 300 |
| Steam Consumption/Cycle (Kg) | 50 | 45 | 30 | 20 | 8 |
| Power Consumption - Steam Heating (Kw) | 1.8 | 1.6 | 1 | 0.8 | 0.4 |
| Power Consumption - Electric Heating (Kw) | - | - | 7 | 5 | 3.5 |
| Water Pressure (Mpa) | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 |
| Steam Pressure (Mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Air Pressure (Mpa) | 0.4-0.5 | 0.4-0.5 | 0.4-0.5 | 0.4-0.5 | 0.4-0.5 |
| Dimesion(mm) | 1920 x 1700 x 2020 | 1875 x 1600 x 1930 | 1440 x 1320 x 1700 | 1285 x 1150 x 1540 | 950 x 800 x 1300 |
| Weight (Kg) | 2900 | 2700 | 1550 | 1100 | 420 |
